Ubiquiti UniFi Access Point U7 Long Range (U7-LR)

Key SpecificationsCoverage

Area: Up to 160 m² (1,750 ft²).Total Throughput: Up to 5 Gbps aggregate data rate.Spatial Streams: 5 spatial streams (3x3 on 5 GHz, 2x2 on 2.4 GHz)

Wired Uplink: 2.5 GbE RJ45 port.Power

Requirement: Powered via 802.3at PoE+ (injector not included)

Client Capacity: Supports 300+ concurrent clients.Core AdvantagesExtended Signal Reach: Optimized antenna design maximizes coverage footprint.

Multi-Link Operation: MLO allows compatible client devices to transmit across bands concurrently.

High-Speed Uplink: The 2.5 GbE port prevents bottlenecks from fast Wi-Fi 7 traffic.Advanced Isolation: Built-in guest traffic isolation and scheduling features.

Technical Comparison: 2.4 GHz vs 5 GHz BandFeature2.4 GHz Band5 GHz BandMIMO Configuration2 x 2 (DL/UL MU-MIMO)3 x 3 (DL/UL MU-MIMO)Max Data Rate688 Mbps (BW40)4.3 Gbps (BW160)Antenna Gain4 dBi6 dBiMax TX Power26 dBm27 dBm
